Ibanez AF75TRS Artcore Hollow Body, Transparent Red

*These are stock photos.

The AF is the most traditional design within the Artcore series. The full-hollow body construction means there are no sound blocks in the body. This construction method produces a rich, complex tone, expressed with a pure voice and full body, the tonal characteristics most highly desired among the discerning Jazz player.

The Ibanez AF75 is a hollow body electric guitar from the Artcore (AF) series. Built for players who demand the traditional look, feel, and warm resonance of a true full-hollow body instrument, it utilizes Linden for the top, back, and sides. Paired with a Nyatoh neck and Rosewood fretboard, it is designed to deliver a rich, well-balanced tone with a focused mid-range. Outfitted with Classic Elite humbucking pickups, this guitar provides nuanced, fat tones that are perfect for jazz, blues, and early rock 'n' roll.

• CASE/GIG BAG: Not Included.

• Linden Top, Back, and Sides
  Provides the acoustic resonance and traditional aesthetic expected of a full hollow body instrument.
• Nyatoh Neck
  Designed to provide a rich mid-low end to the guitar's overall tone.
• Rosewood Fretboard
  Offers a well-balanced, solid tone with a focused mid-range, complete with stylish acrylic block inlays.
• Classic Elite Pickups
  These passive/ceramic humbucking pickups (in both the neck and bridge positions) offer a rich, nuanced tone with a fat low-end response.
• Gibraltar Performer Bridge
  Provides excellent sustain and tuning stability. It features low-positioned saddles for comfortable playability.
• VT60 Tailpiece
  An artistically designed tailpiece that contributes to both great tuning stability and rich string sustain.
• Sure Grip Knobs
  Independent volume and tone controls for each pickup, plus a standard 3-way pickup selector switch for versatile tone shaping.

General Specs

• Neck Type: AF Artcore / Nyatoh / Set-in neck
• Top/Back/Side: Linden top, Linden back, Linden sides
• Fretboard: Bound Rosewood fretboard with Acrylic block inlay
• Frets: Medium frets
• Number of Frets: 20
• Bridge: Gibraltar Performer bridge
• String Spacing: 10.5mm
• Tailpiece: VT60 tailpiece
• Neck Pickup: Classic Elite (H) neck pickup (Passive/Ceramic)
• Bridge Pickup: Classic Elite (H) bridge pickup (Passive/Ceramic)
• Hardware Color: Chrome
• Strings: D'Addario® EXL140
• String Gauge: .010/.013/.017/.030/.042/.052
• Factory Tuning: 1E, 2B, 3G, 4D, 5A, 6E
• Finish: Transparent Red Sunburst (TRS)
• Recommended Case: MF100C (sold separately)

Neck Dimensions

• Scale Length: 628mm (approx. 24.7")
• Width at Nut: 43mm
• Width at 20th Fret: 56.3mm
• Thickness at 1st Fret: 21mm
• Thickness at 9th Fret: 24mm
• Fingerboard Radius: 305mmR

Body Dimensions

• Length: 19 1/2"
• Width: 15 3/4"
• Max Depth: 3 5/8"
